- Double walled construction inner chamber made of Stainless Steel & exterior made of M.S powder coated or Stainless Steel.
- Having a door with a provision to observe the products under testing.
- Gap between the walls is filled with special grade mineral wool for proper insulation to avoid heat loss and thereby saving energy.
- Air Ventilation are placed in incubator.
- Shelves : Stainless steel.
- Temperature Range : 5°C above ambient to 70°C.
- Accuracy/ Uniformity : ± 0.5°C / ± 1°C
- Control : Microprocessor based PID control Auto tune / PLC Based HMI Controller
- Resolution :0.1°C
- Temperature sensor : PT - 100
- Heating : ISI Marked 'U' shaped tubular SS heater
- Air circulation : Blower and ange type motor
- Power supply : 230V / 15A / 50 Hz
- High Temperature safety cut off.
OPTIONAL FEATURES
- PC/ PRINTER INTERFACE UNIT Facility to print records on printer with set values, actual values, date and time with variable print time
- SOFTWARE 21-CFR PART 11 COMPLIANCE SOFTWARE
| Model No. | Internal Size (mm) Width Depth Height | Liters | No.of Shelves |
|---|---|---|---|
| JDJ/BL-01 | 350 x 350 x 350 | 40 | 1 |
| JDJ/BL-02 | 450 x 400 x 500 | 90 | 3 |
| JDJ/BL-03 | 450 x 450 x 610 | 120 | 3 |
| JDJ/BL-04 | 500 x 500 x 900 | 225 | 4 |
| JDJ/BL-05 | 600 x 600 x 900 | 320 | 4 |
* Customize size can be provided on user request
